Tethered X-ray detectors for OR Technology X-ray systems

Digital X-ray detector XenOR 43-139F

XenOR 43-139F [to the product information]
Active area 43 x 43 cm (17" x 17"), tethered, detector based on amorphous Silicon (a-Si) with Caesium Iodide (CsI) scintillator, Pixel pitch 139 µm, exposure control with AED, weight approx. 4 kg (without cable)

The XenOR 43-139F is used in the following X-ray systems:
Amadeo V-DR, Amadeo V-DR mini II, Amadeo V-DR nano II



XenOR 43CLe X-ray detector

XenOR 43CL [to the product information]
Active area 43.4 x 43.4 cm (17.0" x 17.0"), tethered, detector based on amorphous Silicon (a-Si) with Caesium Iodide (CsI) scintillator (thick version for higher DQE), exposure control with AED, pixel pitch 154 µm, weight 3.9 kg (8.6 lbs.)

The XenOR 43CL is used in the following X-ray systems:
Medici, Amadeo V-DR, Amadeo V-DR mini II, Amadeo V-DR nano II


XenOR 35CL X-ray detector

XenOR 35CL [to the product information]
Active area 43.3 x 35.5 cm (17" x 14"), tethered, detector based on amorphous Silicon (a-Si) with Caesium Iodide (CsI) scintillator (thick version for higher DQE), pixel pitch 154 µm, exposure control with AED, weight 3.2 kg (7 lbs.)

The XenOR 35CL is used in the following X-ray systems:
Medici, Amadeo V-DR, Amadeo V-DR mini II, Amadeo V-DR nano II


Varex XRpad2 4343F

Varex XRpad2 4343F [to the product information]
Active area 43.2 x 43.2 cm (17.0" x 17.0"), tethered, detector based on amorphous Silicon (a-Si) with Caesium Iodide (CsI) scintillator, pixel pitch 100 µm, exposure control with AED, weight 3.8 kg (8.4 lbs.)

The Varex XRpad2 4343F is used in the following X-ray systems:
Medici, Amadeo V-DR, Amadeo V-DR mini II, Amadeo V-DR nano II


Varex PaxScan 4343RC

Varex PaxScan 4343RC [to the product information]
Active area 42.4 x 42.4 cm (16.7" x 16.7"), tethered, detector based on amorphous Silicon (a-Si) with Caesium Iodide (CsI) scintillator, pixel pitch 139 µm, exposure control with AED, weight approx. 3.76 kg (8.3 lbs.)

The Varex PaxScan 4343RC is used in the following X-ray systems:
Medici, Amadeo V-DR



Canon ETD FDXA4343R/A

Canon ETD FDXA4343R/A  [to the product information]
Active area 42.6 x 42.5 cm (16.8" x 16.7"), tethered, detector based on amorphous Silicon (a-Si) with Caesium Iodide (CsI) scintillator, Pixel pitch 140 µm, exposure control with AED, weight approx. 4,3 kg

The Canon ETD FDXA4343R/A is used in the following X-ray systems:
Medici, Amadeo V-DR, Amadeo V-DR mini II, Amadeo V-DR nano II





nach oben

Wireless X-ray detectors for OR Technology systems

XenOR 35-150WF - intellegent x-ray detector

XenOR 35-150WF [to the product information]
Active area 35,5 x 43 cm (14" x 17"), wireless, CsI coating optimises digital signal processing, AED detection, pixel density 150 µm, weight approx. 3.3 kg

The XenOR 35-150WF is used in the following X-ray systems::
Medici, Amadeo V mini II, Amadeo V nano II, Leonardo DR nano, Leonardo DR mini II





XenOR 43-100WF - firstclass wireless x ray detector

XenOR 43-100WF [to the product information]
Active area 43 x 43 cm (17" x 17"), wireless, CsI coating optimises digital signal processing, AED detection, pixel density 100 µm with 16-bit ADC for more details, battery capacity up to 8h, weight approx. 3.4 kg

The XenOR 43-100WF is used in the following X-ray systems:
Medici, Amadeo V mini II, Amadeo V nano II





XenOR 43-139WF - digital x-ray detector

XenOR 43-139WF [to the product information]
Active area 43 x 43 cm (17" x 17"), wireless, CsI coating optimises digital signal processing, AED detection, pixel density 139 µm, with fold-out handle, weight approx. 4.6 kg

The XenOR 43-139WF is used in the following X-ray systems:
Medici, Amadeo V mini II, Amadeo V nano II





Digital x ray detector XenOR 35-100WF

XenOR 35-100WF [to the product information]
Active area 35,5 x 43 cm (14" x 17"), first-class wireless X-ray detector in cassette format based on amorphous Silicon (a-Si) with Caesium Iodide (CsI) scintillator, large-capacity battery with a runtime of more than 8h, automatic exposure detection (AED), weight (3.7 kg), pixel pitch of 100 μm

The XenOR 35-100WF is used in the following X-ray systems:
Medici, Amadeo V-DR, Leonardo DR nano, Leonardo DR mini II





Digital x ray detector XenOR 33-100W-flex

XenOR 33-100W-flex [to the product information]
Active area 25 x 33 cm (10" x 13"), compact and robust X-ray detector with flexible layer (no glass) incl. Csl scintillator specially developed for use in equine medicine, narrow edges of only approx. 7 mm on 2 sides, automatic exposure detection (AED), reduced weight (2 kg), picxel pitch 100 µm

The XenOR 33-100W-flex is used in the following X-ray systems:
Amadeo V-DR, Leonardo DR nano, Leonardo DR mini II





Wireless x-ray detektor XenOR 24CW

XenOR 24CW [to the product information]
Active area 24.,6 x 30.7 cm (9.5" x 12.0"), portable wireless detector based on amorphous Silicon (a-Si) with Caesium Iodide (CsI) scintillator (thick Version for higher DQE), pixel pitch 120 µm, exposure control with AED, weight 2.3 kg (5 lbs.)

The XenOR 24CW is used in the following X-ray systems:
Medici, Leonardo DR mini II, Leonardo DR pico






Wireless x-ray detektor Varex XRpad2 4343W

Varex XRpad2 4343W [to the product information]
Active area 43.2 x 43.2 cm (17" x 17"), wireless, detector based on amorphous Silicon (a-Si) with Caesium Iodide (CsI) scintillator, pixel pitch 100 µm, exposure control with AED, weight approx. 3.8 kg (8.4 lbs.)

The Varex XRpad2 4343W is used in the following X-ray systems:
Medici






Wireless x-ray detektor Varex XRpad2 4336

Varex XRpad2 4336 [to the product information]
Active area 35.0 x 42.6 cm (13.8" x 16.8"), portable wireless detector based on amorphous Silicon (a-Si) with Caesium Iodide (CsI) scintillator, pixel pitch 100 µm, exposure control with AED, weight 3.1 kg (6.8 lbs.)

The Varex XRpad2 4336 is used in the following X-ray systems:
Medici, Leonardo DR mini II, Leonardo DR nano






Wireless x-ray detektor Varex XRpad2 3025

Varex XRpad2 3025 [to the product information]
Active area 29.8 x 24.8 cm (11.8" x 9.8"), portable wireless detector based on amorphous Silicon (a-Si) with Caesium Iodide (CsI) scintillator, pixel pitch 100 µm, weight 1.8 kg (6.8 lbs.)

The Varex XRpad2 3025 is used in the following X-ray systems:
Medici, Leonardo DR mini II, Leonardo DR pico
